Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Sealed Power |
| Part Number | H1132CPA |
| Part Description | Piston |
| Bore | 4.040" |
| Compression Distance | 1.090" |
| Dome Volume CC | -5 |
| Head Illustration | 188 |
| Lock Ring | Included |
| Material | Hypereutectic |
| Minimum Clearance | 0.0015 |
| Pin Diameter | 0.912" |
| Pin Type | F |
| Pin Weight Gram | 110 |
| Ring 1 Qty | 2 |
| Ring 1 Width | 1/16" |
| Ring 2 Qty | 1 |
| Ring 2 Width | 1/8" |
| Size | Standard |
| UPC | 019826085894 |
| Weight W Pin Gram | 519 |
| Weight w/o Pin Gram | 409 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2008-2009 Buick Allure | All Trims | 8 Cyl 5.3L |
| 2008-2009 Buick LaCrosse | All Trims | 8 Cyl 5.3L |
| 2005-2007 Buick Rainier | All Trims | 8 Cyl 5.3L |
| 2007-2009 Chevrolet Avalanche | All Trims | 8 Cyl 5.3L |
| 2009 Chevrolet Colorado | All Trims | 8 Cyl 5.3L |
| 2009 Chevrolet Express 1500 | All Trims | 8 Cyl 5.3L |
| 2005-2009 Chevrolet Express 2500 | All Trims | 8 Cyl 4.8L |
| 2005-2009 Chevrolet Express 3500 | All Trims | 8 Cyl 4.8L |
| 2006-2009 Chevrolet Impala | All Trims | 8 Cyl 5.3L |
| 2006-2007 Chevrolet Monte Carlo | All Trims | 8 Cyl 5.3L |
