Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Sealed Power |
| Part Number | H675CP |
| Part Description | Piston |
| Bore | 3.8110" |
| Compression Distance | 1.607 |
| Head Illustration | 44 |
| Head Type | Recessed Head .170 deep; DUROSHIELD~ skirt coated piston |
| Minimum Clearance | See Piston Fitting Information on carton label |
| Part Material | Hypereutectic |
| Pin Diameter | 23.17 |
| Pin Offset | 0.762 |
| Pin Type | P |
| Ring 1 Qty | 2 |
| Ring 1 Width | 1.50mm |
| Ring 2 Qty | 1 |
| Ring 2 Width | 4.00mm |
| UPC | 614046703810 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 1989-1995 Ford Thunderbird | All Trims | 6 Cyl 3.8L |
| 1989-1990 Mercury Cougar | All Trims | 6 Cyl 3.8L |
