Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Sealed Power |
| Part Number | H857CP |
| Part Description | Piston |
| Bore | 4" |
| Compression Distance | 1.325" |
| Dome Volume CC | - 007.0 |
| Head Illustration | 43 |
| Material | Hypereutectic |
| Minimum Clearance | See Piston Fitting Information on carton label |
| Pin Diameter | 0.9451" |
| Pin Offset | 0.762 mm |
| Pin Type | P |
| Ring 1 Qty | 2 |
| Ring 1 Width | 1.50mm |
| Ring 2 Qty | 1 |
| Ring 2 Width | 3.00mm |
| Size | Standard |
| UPC | 614046630604 |
| Weight W Pin Gram | 00610.+/- 00. |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2003 Chevrolet Express 2500 | All Trims | 8 Cyl 6.0L |
| 2003 Chevrolet Express 3500 | All Trims | 8 Cyl 6.0L |
| 2001-2003 Chevrolet Silverado 1500 HD | All Trims | 8 Cyl 6.0L |
| 1999-2003 Chevrolet Silverado 2500 | All Trims | 8 Cyl 6.0L |
| 2001-2003 Chevrolet Silverado 2500 HD | All Trims | 8 Cyl 6.0L |
| 2001-2003 Chevrolet Silverado 3500 | All Trims | 8 Cyl 6.0L |
| 2000-2003 Chevrolet Suburban 2500 | All Trims | 8 Cyl 6.0L |
| 2003 GMC Savana 2500 | All Trims | 8 Cyl 6.0L |
| 2003 GMC Savana 3500 | All Trims | 8 Cyl 6.0L |
| 2001-2003 GMC Sierra 1500 | All Trims | 8 Cyl 6.0L |
