Vehicle Specific
Check if it fits by entering your vehicle info| Brand | TYC |
| Part Number | 13337 |
| Part Description | Engine Coolant Radiator |
| Bottom Header | 2.5x19.76 |
| Core Height | 18.82 |
| Core Length | 23.46 |
| Core Material | Aluminum |
| Core Thickness | 1.57 |
| Engine Oil Cooler Included | No |
| Fin Count (every 4") | 64 |
| Fin Wave Height (in) | 0.31 |
| Find Wave Pitch | 3.2 |
| Flow Configuration | Crossflow |
| Inlet Connection Type | Hose Clamp |
| Inlet Diameter | 1.50 |
| No. Of Rows | 1 |
| UPC | 762405911830 |
| OE Part Number | 52028818AD |
| Outlet Connection Type | Hose Clamp |
| Outlet Diameter | 1.77 |
| TOC Distance (IN) | 12.01 |
| Top Header | 2.5x19.76 |
| Total Fin Row Count | 48 |
| Total Tube Count | 47 |
| Transmission Oil Cooler Included | Yes |
| Transmission Oil Cooler Type | Plate Oil Cooler |
| Tube Count (every 4") | 10 |
| Tube Width x Height | 40x2 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2000-2003 Dodge Dakota | All Trims | 6 Cyl 3.9L |
| 2000-2009 Dodge Dakota | All Trims | 8 Cyl 4.7L |
| 2004 Dodge Dakota | All Trims | 6 Cyl 3.7L |
| 2000 Dodge Durango | All Trims | 8 Cyl 5.2L |
| 2000 Dodge Durango | All Trims | 8 Cyl 5.9L |
| 2001-2003 Dodge Durango | All Trims | 8 Cyl 4.7L |
