Vehicle Specific
Check if it fits by entering your vehicle info| Brand | TYC |
| Part Number | 13388 |
| Part Description | Engine Coolant Radiator |
| Bottom Header | 1.96x19.45 |
| Core Height | 18.66 |
| Core Length | 25.04 |
| Core Material | Aluminum |
| Core Thickness | 0.63 |
| Engine Oil Cooler Included | No |
| Fin Count (every 4") | 78 |
| Fin Wave Height (in) | 0.20 |
| Find Wave Pitch | 2.6 |
| Flow Configuration | Crossflow |
| Inlet Connection Type | Hose Clamp |
| Inlet Diameter | 1.38 |
| No. Of Rows | 1 |
| UPC | 762405259093 |
| OE Part Number | 25310-3M300 |
| Outlet Connection Type | Hose Clamp |
| Outlet Diameter | 1.38 |
| TOC Distance (IN) | 11.02 |
| Toc Inlet Diameter (in) | 0.47 |
| Toc Inlet Type | Tube fitting |
| TOC Outlet Diameter (IN) | 0.47 |
| Toc Outlet Type | Tube fitting |
| Top Header | 1.96x19.45 |
| Total Fin Row Count | 68 |
| Total Tube Count | 67 |
| Transmission Oil Cooler Included | Yes |
| Transmission Oil Cooler Type | Plate Oil Cooler |
| Tube Count (every 4") | 15 |
| Tube Width x Height | 16x2 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2011-2014 Hyundai Genesis | All Trims | 6 Cyl 3.8L |
