Check if it fits by entering your vehicle info| Brand | TYC |
| Part Number | 13473 |
| Part Description | Engine Coolant Radiator |
| Bottom Header | 2.3x31.37 |
| Core Height | 30.14 |
| Core Length | 15.75 |
| Core Material | Aluminum |
| Core Thickness | 1.02 |
| Engine Oil Cooler Included | No |
| Fin Count (every 4") | 68 |
| Fin Wave Height (in) | 0.20 |
| Find Wave Pitch | 3 |
| Flow Configuration | Downflow |
| Inlet Connection Type | Hose Clamp |
| Inlet Diameter | 1.40 |
| No. Of Rows | 1 |
| UPC | 762405259031 |
| OE Part Number | 92456750 |
| Outlet Connection Type | Quick Connect (Spring Lock) |
| Outlet Diameter | 1.32 |
| TOC Distance (IN) | 14.76 |
| Toc Inlet Diameter (in) | 0.37 |
| Toc Inlet Type | Quick Connect |
| TOC Outlet Diameter (IN) | 0.37 |
| Toc Outlet Type | Quick Connect |
| Top Header | 2.02x31.37 |
| Total Fin Row Count | 118 |
| Total Tube Count | 117 |
| Transmission Oil Cooler Included | Yes |
| Transmission Oil Cooler Type | Plate Oil Cooler |
| Tube Count (every 4") | 16 |
| Tube Width x Height | 26x1.5 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2012-2015 Chevrolet Caprice | PPV | 8 Cyl 6.0L |
| 2014-2016 Chevrolet SS | All Trims | 8 Cyl 6.2L |
