Check if it fits by entering your vehicle info| Brand | TYC |
| Part Number | 13516 |
| Part Description | Engine Coolant Radiator |
| Bottom Header | 2.02x31.41 |
| Core Height | 30.14 |
| Core Length | 15.75 |
| Core Material | Aluminum |
| Core Thickness | 1.02 |
| Engine Oil Cooler Included | No |
| Fin Count (every 4") | 78 |
| Fin Wave Height (in) | 0.20 |
| Find Wave Pitch | 2.6 |
| Flow Configuration | Downflow |
| Inlet Connection Type | Hose Clamp |
| Inlet Diameter | 1.28 |
| No. Of Rows | 1 |
| UPC | 762405259024 |
| OE Part Number | 19010-5J2-A01 |
| Outlet Connection Type | Hose Clamp |
| Outlet Diameter | 1.28 |
| Top Header | 2.02x31.41 |
| Total Fin Row Count | 118 |
| Total Tube Count | 117 |
| Transmission Oil Cooler Included | No |
| Tube Count (every 4") | 16 |
| Tube Width x Height | 26x1.5 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2015-2020 Acura TLX | All Trims | 6 Cyl 3.5L |
| 2017 Acura TLX | All Trims | All Engines |
