Vehicle Specific
Check if it fits by entering your vehicle info| Brand | TYC |
| Part Number | 1454 |
| Part Description | Engine Coolant Radiator |
| Accessories Included | OC Adapters (1/2"-2 UNF) and Speed Nut (M6 x P1.) and Cilp for S.P. |
| Bottom Header | 3.17" x 18.65" |
| Core Size | 27.56" x 18.11" x 2.2" |
| Flow Configuration | Crossflow |
| Inlet Connection Type | Hose Clamp |
| Inlet Diameter | 1.77" |
| Manufactured Material | Plastic/Aluminum |
| UPC | 762405252841 |
| OE Part Number | F2TZ 8005 MA |
| Outlet Connection Type | Hose Clamp |
| Outlet Diameter | 1.77" |
| Rows | 1 |
| TOC Distance | 12.01" |
| Top Header | 3.17" x 18.65" |
| Transmission Oil Cooler Included | Yes |
| Transmission Oil Cooler Type | Concentric Oil Cooler |
| Year Make Model | Trim | Engine |
|---|---|---|
| 1987-1992 Ford Bronco | All Trims | 6 Cyl 4.9L |
| 1992-1997 Ford F-150 | All Trims | 6 Cyl 4.9L |
| 1992-1996 Ford F-250 | All Trims | 6 Cyl 4.9L |
| 1992-1996 Ford F-350 | All Trims | 6 Cyl 4.9L |
