Brand | TYC |
Part Number | 2325 |
Part Description | Engine Coolant Radiator |
Bottom Header | 2.01x29.13 |
Core Height | 28.27 |
Core Length | 15.75 |
Core Material | Aluminum |
Core Thickness | 1.02 |
Engine Oil Cooler Included | No |
Fin Count (every 4") | 68 |
Fin Wave Height (in) | 0.31 |
Find Wave Pitch | 3 |
Flow Configuration | Downflow |
Inlet Connection Type | Hose Clamp |
Inlet Diameter | 1.38 |
No. Of Rows | 1 |
Outlet Connection Type | Hose Clamp |
Outlet Diameter | 1.38 |
Toc Distance (in) | 14.76 |
Toc Inlet Diameter (in) | 0.39 |
Toc Inlet Type | Tube fitting |
Toc Outlet Diameter (in) | 0.39 |
Toc Outlet Type | Tube fitting |
Top Header | 2.01x29.13 |
Total Fin Row Count | 72 |
Total Tube Count | 71 |
Transmission Oil Cooler Included | Yes |
Transmission Oil Cooler Type | Concentric Oil Cooler |
Tube Count (every 4") | 10 |
Tube Width X Height | 26x2 |
UPC | 762405251271 |
Year Make Model | Trim | Engine |
---|---|---|
2000-2004 Toyota Avalon | All Trims | 6 Cyl 3.0L |
