Vehicle Specific
Check if it fits by entering your vehicle info| Brand | TYC |
| Part Number | 2711 |
| Part Description | Engine Coolant Radiator |
| Bottom Header | 2.91" x 29.74" |
| Core Height | 29.06" |
| Core Length | 26.97" |
| Core Material | Aluminum |
| Core Thickness | 1.65" |
| EOC | No |
| Fin Count (Every 4"): 68 | 68 |
| Fin Wave Height | 0.31" |
| Find Wave Pitch | 3 |
| Flow Configuration | Crossflow |
| Inlet Connection Type | Hose Clamp |
| Inlet Diameter | 2.01" |
| No. Of Rows | 1 |
| UPC | 762405257044 |
| OE Part Number | 55056816AA |
| Outlet Connection Type | Hose Clamp |
| Outlet Diameter | 2.01" |
| TOC | No |
| Top Header | 2.91 x 29.74 |
| Total Fin Row Count | 74 |
| Total Tube Count | 73 |
| Tube Count (Every 4"): 10 | 10 |
| Tube Width x Height | 16" x 2" and 22" x 2" |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2003-2007 Dodge Ram 2500 | All Trims | 6 Cyl 5.9L |
| 2007-2009 Dodge Ram 2500 | All Trims | 6 Cyl 6.7L |
| 2003-2007 Dodge Ram 3500 | All Trims | 6 Cyl 5.9L |
| 2007-2009 Dodge Ram 3500 | All Trims | 6 Cyl 6.7L |
