Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Gates |
| Part Number | 34717 |
| Part Description | OE Type Engine Coolant Thermostat |
| By-Pass Flange Diameter | 1.38" |
| Depth from Flange | 1.8" |
| Design | Bottom By-Pass |
| Flange Diameter | 1.57" |
| Height from Flange | 0.84" |
| Includes Installation Tool | No |
| Jiggle Pin/Check Valve | Yes |
| Material | Steel, Copper |
| Number of Gaskets | 0 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 2 |
| OE Comparison Rating | OE Performance |
| Seal Type | O-Ring |
| Temperature (C) | 82 |
| Temperature (F) | 180 |
| Total Height | 2.64" |
| Type | OE Type Thermostat |
| UPC | 770075631965 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2016-2018 Buick Envision | All Trims | 4 Cyl 2.0L |
| 2015-2017 Buick Regal | All Trims | 4 Cyl 2.0L |
| 2013-2014 Cadillac ATS | All Trims | 6 Cyl 3.6L |
| 2015-2018 Cadillac ATS | All Trims | 4 Cyl 2.0L |
| 2016-2017 Cadillac CT6 | All Trims | 4 Cyl 2.0L |
| 2011-2014 Cadillac CTS | All Trims | 6 Cyl 3.0L |
| 2011-2014 Cadillac CTS | All Trims | 6 Cyl 3.6L |
| 2015-2018 Cadillac CTS | All Trims | 4 Cyl 2.0L |
| 2010-2011 Cadillac STS | All Trims | 6 Cyl 3.6L |
| 2010-2014 Chevrolet Camaro | All Trims | 6 Cyl 3.6L |
