Toyota Land Cruiser Radiator
Select vehicle to guarantee fit
Make
Model
Year
< Back to View All
Cooling Systems, Fans & Radiators
- Department
- Brands
- Prices
$336.95 MSRP:$489.51You Save: $152.56 (32%)Product Specifications- Item Dimensions: 34.9 x 26.3 x 8.6 inches
- Item Weight: 34.00 Pounds
- Part Description: Toyota Land Cruiser Radiator
$247.52Product Specifications- Core Height: 23.2500"
- Core Thickness: 1.8750"
- Core Width: 28.0620"
- Inlet Diameter: 1.5000"
- Outlet Diameter: 1.6250"
- UPC: 042511178212
- Part Description: Toyota Land Cruiser Engine Coolant Radiator
$248.86Product Specifications- Bottom Header: 2 11/16" x 28 3/8"
- Core Size: 16 3/4" x 27 3/8" x 1 7/16"
- Manufactured Material: Plastic/Aluminum
- OE Part Number: 16400-66081
- Rows: 2
- Top Header: 2 11/16" x 28 3/8"
- UPC: 762405213132
- Part Description: Toyota Land Cruiser Engine Coolant Radiator
$423.16Product Specifications- Bottom Hose Fitting (in): 1 1/2 Right
- Box Height (in): 7 4/16
- Box Length (in): 22 3/4
- Box Weight (lbs): 26
- Box Width (in): 28 11/16
- Core Length: 15 3/4
- Core Material: Copper
- Core Thickness: 2 5/16
- Core Width: 23 15/16
- Cross-flow/ Down-flow: Down Flow
- Csf Cap Number: 4502
- Hazardous Material: No
- Inlet Length (in): 23 15/16
- Inlet Width (in): 2 13/16
- No. Of Rows: 4
- OE Part Number: 16400-61051, 12, CU12
- Oil Cooler (in): 15 3/8 (high-effeciency Concentric Type)
- Outlet Length(in): 23 15/16
- Outlet Width: 2 13/16
- Radiator Cap Supplied: No
- Tank Material: Brass
- Tech Note: Rugged ALL METAL model.
- Top Hose Fitting (in): 1 1/2 Left
- UPC: 710353027080
- Part Description: Toyota Land Cruiser Engine Coolant Radiator
$328.36 MSRP:$477.03You Save: $148.67 (32%)Product Specifications- Other Names: Radiator
- Item Dimensions: 46.2 x 34.0 x 9.5 inches
- Item Weight: 36.10 Pounds
- Fitment Type: Direct Replacement
- Replaces: 16400-50381, 16400-50383, 16400-50382
- Part Description: Toyota Land Cruiser Radiator Assembly
$303.68Product Specifications- Core Material: Aluminum
- Height: 20 1/16"
- Inlet: 1 1/2"
- Inlet Header: 27 3/16" x 2 3/16"
- Outlet: 1 5/8"
- Outlet Header: 27 3/16" x 2 3/16"
- Row: 2
- Tank Material: Plastic
- Thickness: 1 3/4"
- TOC: Plated; 15 3/8"
- UPC: 671607742336
- Width: 27 11/16"
- Part Description: Toyota Land Cruiser Complete Radiator
$408.71Product Specifications- Bottom Hose Fitting (in): 1 5/8 Right
- Box Height (in): 6 14/16
- Box Length (in): 33 5/8
- Box Weight (lbs): 30
- Box Width (in): 24 1/2
- Core Length: 16 3/4
- Core Material: Copper
- Core Thickness: 1 11/16
- Core Width: 28 11/16
- Cross-flow/ Down-flow: Down Flow
- Csf Cap Number: 4502
- Hazardous Material: No
- Inlet Length (in): 29 1/8
- Inlet Width (in): 2 1/2
- No. Of Rows: 3
- OE Part Number: 16400-66081, 221-3128, CU1917, 8011918
- Oil Cooler (in): 15 3/8 (high-effeciency Concentric Type)
- Outlet Length(in): 29 1/8
- Outlet Width: 2 1/2
- Radiator Cap Supplied: No
- Tank Material: Brass
- Tech Note: Rugged ALL METAL model.
- Top Hose Fitting (in): 1 1/2 Left
- UPC: 710353025178
- Part Description: Toyota Land Cruiser Engine Coolant Radiator
$370.22 MSRP:$545.95You Save: $175.73 (33%)Product Specifications- Other Names: Radiator
- Item Dimensions: 40.4 x 6.8 x 32.6 inches
- Item Weight: 30.60 Pounds
- Replaces: 16400-50212, 16400-50211, 16400-50210
- Part Description: Toyota Land Cruiser Radiator Assembly
$233.18Product Specifications- Core Height: 20.0620"
- Core Thickness: 1.6250"
- Core Width: 27.3120"
- Inlet Diameter: 1.5000"
- Outlet Diameter: 0.9370"
- UPC: 042511178205
- Part Description: Toyota Land Cruiser Engine Coolant Radiator
$247.36Product Specifications- Bottom Hose Fitting (in): 1 1/2 Right
- Box Height (in): 6 14/16
- Box Length (in): 24 9/16
- Box Weight (lbs): 19
- Box Width (in): 24 1/2
- Core Length: 17 1/8
- Core Material: Copper
- Core Thickness: 1 11/16
- Core Width: 19 3/16
- Cross-flow/ Down-flow: Down Flow
- Csf Cap Number: 4501
- Hazardous Material: No
- Inlet Length (in): 19 11/16
- Inlet Width (in): 2 13/16
- No. Of Rows: 3
- OE Part Number: 180, 16400-60012, CU180, 8010180, 16400-60011, 16400-61020, CU686
- Outlet Length(in): 19 11/16
- Outlet Width: 2 7/16
- Radiator Cap Supplied: No
- Tank Material: Brass
- Tech Note: ALL METAL model.
- Top Hose Fitting (in): 1 1/2 Left
- UPC: 710353001806
- Part Description: Toyota Land Cruiser Engine Coolant Radiator
- $487.51 MSRP:
$718.90You Save: $231.39 (33%)Product Specifications- Other Names: Radiator
- Item Dimensions: 36.7 x 29.4 x 8.3 inches
- Item Weight: 32.40 Pounds
- Fitment Type: Direct Replacement
- Part Description: Toyota Land Cruiser Radiator Assembly
$177.82Product Specifications- Bottom Hose Fitting (in): 1 11/16 Right
- Box Height (in): 6 7/8
- Box Length (in): 34 3/8
- Box Weight (lbs): 27
- Box Width (in): 30 13/16
- Core Length: 23 1/4
- Core Material: Aluminum
- Core Thickness: 2 1/16
- Core Width: 27 1/2
- Cross-flow/ Down-flow: Down Flow
- Csf Cap Number: 4514
- Hazardous Material: No
- Inlet Length (in): 28 1/8
- Inlet Width (in): 2 7/16
- No. Of Rows: 2
- Oil Cooler (in): 15 3/8 (high-efficiency Plate Type)
- Outlet Length(in): 28 1/8
- Outlet Width: 2 7/16
- Radiator Cap Supplied: No
- Tank Material: Plastic
- Tech Note: O.E.M. style Plastic tanks & Aluminum core.
- Top Hose Fitting (in): 1 1/2 Left
- UPC: 710353038215
- Part Description: Toyota Land Cruiser Engine Coolant Radiator
$259.14Product Specifications- Bottom Header: 2 11/16" x 28 3/8"
- Core Size: 20 1/16" x 27 1/4" x 2 1/16"
- Manufactured Material: Plastic/Aluminum
- OE Part Number: 16400-50290
- Rows: 2
- Top Header: 2 11/16" x 28 3/8"
- UPC: 762405253008
- Part Description: Toyota Land Cruiser Engine Coolant Radiator
- $401.59 MSRP:
$592.21You Save: $190.62 (33%)Product Specifications- Other Names: Radiator
- Item Dimensions: 36.8 x 25.8 x 7.2 inches
- Item Weight: 27.80 Pounds
- Fitment Type: Direct Replacement
- Replaces: 16400-66080
- Part Description: Toyota Land Cruiser Radiator Assembly
$401.49Product Specifications- Bottom Hose Fitting (in): 1 1/2 Right
- Box Height (in): 6 14/16
- Box Length (in): 33 5/8
- Box Weight (lbs): 29
- Box Width (in): 24 1/2
- Core Length: 16 3/4
- Core Material: Copper
- Core Thickness: 1 11/16
- Core Width: 28 11/16
- Cross-flow/ Down-flow: Down Flow
- Csf Cap Number: 4502
- Hazardous Material: No
- Inlet Length (in): 29 1/8
- Inlet Width (in): 2 1/2
- No. Of Rows: 3
- OE Part Number: 13, 8010013, 16400-61140, CU13
- Oil Cooler (in): 15 3/8 (high-effeciency Concentric Type)
- Outlet Length(in): 29 1/8
- Outlet Width: 2 1/2
- Radiator Cap Supplied: No
- Tank Material: Brass
- Tech Note: Rugged ALL METAL model.
- Top Hose Fitting (in): 1 1/2 Left
- UPC: 710353027097
- Part Description: Toyota Land Cruiser Engine Coolant Radiator
- $400.36 MSRP:
$590.40You Save: $190.04 (33%)Product Specifications- Other Names: Radiator
- Item Dimensions: 37.7 x 34.3 x 8.3 inches
- Item Weight: 31.70 Pounds
- Fitment Type: Direct Replacement
- Part Description: Toyota Land Cruiser Radiator Assembly
$315.01Product Specifications- Bottom Hose Fitting (in): 1 1/2 Right
- Box Height (in): 6 14/16
- Box Length (in): 24 9/16
- Box Weight (lbs): 22
- Box Width (in): 24 1/2
- Core Length: 17 1/8
- Core Material: Copper
- Core Thickness: 2 5/16
- Core Width: 19 3/16
- Cross-flow/ Down-flow: Down Flow
- Csf Cap Number: 4501
- Hazardous Material: No
- Inlet Length (in): 19 11/16
- Inlet Width (in): 2 13/16
- No. Of Rows: 4
- OE Part Number: 16400-60012, 16400-60011, 16400-61020, 1959
- Outlet Length(in): 19 11/16
- Outlet Width: 2 13/16
- Radiator Cap Supplied: No
- Tank Material: Brass
- Tech Note: ALL METAL model.
- Top Hose Fitting (in): 1 1/2 Left
- UPC: 710353028889
- Part Description: Toyota Land Cruiser Engine Coolant Radiator
$153.12Product Specifications- Bottom Hose Fitting (in): 1 5/8 Right
- Box Height (in): 7 1/16
- Box Length (in): 35 15/16
- Box Weight (lbs): 24
- Box Width (in): 28 7/16
- Core Length: 20 1/16
- Core Material: Aluminum
- Core Thickness: 2 1/16
- Core Width: 27 1/16
- Cross-flow/ Down-flow: Down Flow
- Csf Cap Number: 4503
- Hazardous Material: No
- Inlet Length (in): 28 1/8
- Inlet Width (in): 2 7/16
- No. Of Rows: 2
- OE Part Number: 2282, 16400-50290, 2755, 16400-50211, CU2282, 8012755, CU2755, 8012282, 16400-50210
- Oil Cooler (in): 15 3/8 (high-efficiency Plate Type)
- Outlet Length(in): 28 1/8
- Outlet Width: 2 7/16
- Radiator Cap Supplied: No
- Tank Material: Plastic
- Tech Note: O.E.M. style Plastic tanks & Aluminum core;Manufactured with steel crimp strips to strengthen Radiator by 40% over O.E.
- Top Hose Fitting (in): 1 1/2 Left
- UPC: 710353030066
- Part Description: Toyota Land Cruiser Engine Coolant Radiator
Product Specifications- Core Material: Aluminum
- Height: 20 1/16"
- Inlet: 1 1/2"
- Inlet Header: 27 3/16" x 2 3/16"
- Outlet: 1 5/8"
- Outlet Header: 27 3/16" x 2 3/16"
- Row: 1
- Tank Material: Plastic
- Thickness: 1"
- TOC: Concentric
- UPC: 671607750539
- Width: 27 11/16"
- Part Description: Toyota Land Cruiser Complete Radiator
Product Specifications- Core Height: 16.8120"
- Core Thickness: 1.9370"
- Core Width: 28.2500"
- Inlet Diameter: 1.5000"
- Outlet Diameter: 1.6870"
- UPC: 042511174825
- Part Description: Toyota Land Cruiser Engine Coolant Radiator
Denso® Radiators for Toyota Land Cruiser
PartNumber: 221-9362Product Specifications- Core Height: 16.7300"
- Core Thickness: 1.4200"
- Core Width: 28.2900"
- Inlet Diameter: 1.5000"
- Outlet Diameter: 1.6500"
- UPC: 042511225688
- Part Description: Toyota Land Cruiser Radiators
- Product Specifications
- Other Names: Radiator
- Item Dimensions: 33.3 x 6.4 x 24.7 inches
- Item Weight: 35.10 Pounds
- Fitment Type: Direct Replacement
- Replaces: 16400-61190
- Part Description: Toyota Land Cruiser Radiator Assembly
- Product Specifications
- Other Names: Radiator
- Item Dimensions: 35.9 x 26.3 x 8.8 inches
- Item Weight: 13.80 Pounds
- Fitment Type: Direct Replacement
- Replaces: 16400-61050
- Part Description: Toyota Land Cruiser Radiator Assembly
- Product Specifications
- Other Names: Radiator
- Item Dimensions: 30.5 x 9.2 x 25.9 inches
- Item Weight: 28.30 Pounds
- Fitment Type: Direct Replacement
- Part Description: Toyota Land Cruiser Radiator Assembly
